Applied Materials Centura EPI Epitaxial Deposition, reduced pressure, 2 chamber for Sale


SDI fabsurplus.com is pleased to announce the availability of the following listed used Applied Materials Centura EPI Epitaxial Deposition, reduced pressure, 2 chamber.
Please click on the "Get Quote" button at the end of the Centura EPI description, if you'd like to get a quotation, photos and specifications of this Epitaxial Deposition, reduced pressure, 2 chamber, and your request for this equipment will be forwarded to our SDI sales representatives automatically.
This Applied Materials Centura EPI Epitaxial Deposition, reduced pressure, 2 chamber is available for immediate sale.
Crating, refurbishment and delivery for this equipment can be quoted on request.


Applied Materials Centura EPI Equipment Details

SDI ID: 108557
Manufacturer: Applied Materials
Model: Centura EPI
Description: Epitaxial Deposition, reduced pressure, 2 chamber
Version: 300 mm
Vintage: 01.05.2002
Quantity: 1
Sales Condition: as is where is
Lead Time: immediately
Sales Price: Inquire
Comments:

Deinstalled, warehoused. Can be inspected by appointment.

Platform Type: 300mm Centura
Application Level 1 : Reduced Pressure
Application Level 2 : Reduced Pressure
First in Fab System or Apps : No
Ch-A : (RH3) Reduced PRESSURE EPI
Ch-B : (RH3) Reduced PRESSURE EPI
Ch-C : Empty
Ch-D : Empty
Electrical: SEMI

Chamber A Configuration

Thickness Control Option AccuSETT 2
Recipe Control AccuSETT Yes
Lamp Type
Ushio BNA8

Chamber B Configuration

Thickness Control Option AccuSETT 2
Recipe Control AccuSETT Yes
Lamp Type
Ushio BNA8

Gas Delivery Configuration
Pump Purge: Yes
Regulator and Displays: Transducers and Regulators
Transducer Display Type: SI (KPA)
H2 Leak Detector: SINGLE

MFC Configuration
#        CH A       CH B
Slot 1   N2          N2
Slot 2   HCL         HCL
Slot 3   SiH4        SiH4
Slot 5   Si2H6       D-DOP#1
Slot 6   HCL         D-DOP#2
Slot 7   DCS         DCS
Slot 8   GeH4        GeH4
Slot 9   M-DOP#1     M-DOP#1
Slot 10  M-DOP#2     M-DOP#2

Mainframe Configuration
Mainframe Type: STD CENTURA
Loadlocks:BATCH LOAD LOCK
Upper Frame H2 Leak Detector:Present
Mass Flow Verification: YES
Multi Water Clean: NO MVC FOR 4 CHAMBER SYSTEM
Wafer Transfer Robot: YASKAWA
ORIENTER: PRE ALIGNER
End effecter: Edge grip PEEK material
Wafer storage: 2 Slot
Wafer Mapping: LED sensor Detection
Number of Load Parts: Two
