SDI fabsurplus.com is pleased to announce the availability of the following listed used Teradyne Magnum 2X GVLC VP Automated Test System.
Please click on the "Get Quote" button at the end of the Magnum 2X GVLC VP description, if you'd like to get a quotation, photos and specifications of this Automated Test System, and your request for this equipment will be forwarded to our SDI sales representatives automatically.
This Teradyne Magnum 2X GVLC VP Automated Test System is available for immediate sale.
Crating, refurbishment and delivery for this equipment can be quoted on request.
| SDI ID: | 116556 |
|---|---|
| Manufacturer: | Teradyne |
| Model: | Magnum 2X GVLC VP |
| Description: | Automated Test System |
| Version: | TEST |
| Vintage: | 01.12.2013 |
| Quantity: | 1 |
| Sales Condition: | as is where is |
| Lead Time: | immediately |
| Sales Price: | Inquire |
| Comments: | MAGNUM_2X Specification: FEATURE Specification Maximum I/O Pins 10,240 pins ECR Size (per 64 pins) 36Gb and 72Gb RCM Size (per 16 pins) 36Mb DBM Size (per APG) 18Gb and 36Gb EBM (per pin) 16Kb data source Vector Depth 64-128MV and 128-256MV APG Register 24X, 24Y (40 max) Data Word Width 36 bits (18 DDR) On-the-fly Timing Sets 31 Total Timing Accuracy +/- 350pS Drive & Compare Levels -1V to 6.5V 0 to 12.5V VIHH Selectable pin-by-pin DPS 1 per 8 pins DPS Voltage Range -15V to +15V DPS Current Range 0 to 600mA in 6 ranges PMU 1 per 16 pins PMU Voltage Range -2.5V to +12.75V PMU Current Range 0 to 20mA in 5 ranges PTU 10.24 PTU Voltage Range -1.5V to +12V (2mA) PTU Current Range 0 to 28mA in 8 ranges Tester Workstation PC Operating System Windows Server 2003 Test Language C Test Type Memory, Logic, and Mixed Mode Product: HiFix(Base board) for Magnum2X ▪Model: Base Board Magnum_2x // M500HT ▪Manufacturer: TSE ▪Manufacturing Year: 2013 |
Get Quote |
