1998, Fabsurplus.com is
one of the most popular websites for buying and selling used Semiconductor, Test, Assembly, SMT , Flat
Panel Display , Solar Cell and Solar Module Assembly Equipment.
We cover the globe from offices in the USA, Europe and Asia.
Here is our current
line-up of experienced sales professionals:-
Stephen Howe (Italy
and Texas) Tel (USA) +1 830-388-1071 and Italy (+39) 335-710-7756
List 1 = Equipment and
complete/partial production lines
List 2 = Chillers
List 3 = Vacuum Pumps
List 4 = Spares and
If you would like to
buy any of these items, please send us a mail and let us know the SDI ID
number, manufacturer and model of the item of interest.
You can also find all
of these items on our website at www.fabsurplus.com,
along with photos , a technical description, and pricing in many cases.
included a link to the sales item details page for each sales item in the
attached spreadsheet, which, in many cases, will take you to the details of the
equipment in question, including photos, a specification and PRICING.
I am looking forwards
to receiving your mails soon.
We are also keen in
getting your lists of any surplus equipment, fab production lines, and
major subsystems which you may have for sale, surplus to requirements.
happy to organise the orderly liquidation of facilities or stocks of surplus
equipment on request via closed bidding.
Turn your unused
capital inventory into cash , save money and help save the planet at the same
Thanks a lot, and best
wishes to all.
SDI Fabsurplus Group Stephen Howe
Mobile (USA) : +1 830-388-1071
Mobile (Italy) : +39 335-710-7756
The Capacity Calculation for the lines is as follows:
Cycle time of each tabber per cell produced: 5.23
Hours of production Per shift: 12 hours
Number of Tabbers per line: qty 7
Each module is 245 watts (60 cells, 4W per cell).
KW per line produced for each shift: 211.505736 KW
Number of shifts per day: 2
Number of Lines: 2
Number of Working Days Per Year: 337
Total MWatt per year: 285.109732
We assume total losses of 10%.
Total MWatt production per year: 256.60 MW
The engineering team who installed and supported the line are available to
answer any further technical questions, and also for eventual dismantling.
Inspection of the line is available by appointment.
To schedule an inspection , please contact our sales manager in the UK, Duncan Lovett. Duncan has a wide-ranging experience of industrial equipment sales and marketing , built up over the years since 1983. Duncan can be contacted as follows:
Manufacturer: Baccini Model: 35MW Solar Cell Line Description: Solar Cell Print line for Mono or Poly Crystalline Solar Cells Comments: De-installed and warehoused in March 2012. Location: Port Klang, Malaysia. Front end of line (Printers and dryers, chip and crack camera) s/n: 900140650010 Purchased from Q-Cells. Fully Automated Line Polycrystalline Solar Cells 16% plus efficiency cells
Equipment includes the following:- 1 x Redmann loader-cassette to conveyor 1 x Conveyor 1 x Chip and crack camera 1 x Baccini Printer 1 1 x Baccini Dryer 1 1 x Baccini Printer 2 1 x Baccini Dryer 2 1 x Baccini printer 3 1 x Centrotherm dryer 1 x Centrotherm fast firing furnace 1 x Centrotherm cooler 1 x Centrotherm output table 1 x Innolas laser 1 x Baccini unloader to stack 1 x Baccini color sorter with flipper 1 x Baccini electrical tester 1 x Baccini sorter 1 1 x Baccini sorter 2
10MW Solar Cell Line Model:
Monocyrstalline Description: 10MW
Solar Cell Manufacturing line with
PECVD Comments: Fully operational
Part Automated and Part Batch
Process Monocrystalline Solar Cells
Producing 17% efficiency Cell Please see attachments for Equipment
list with photos and the equipment
Equipment list: *Edge Isolation Machine Brand : CETC
Model : M42200-21 *PECVD Machine
Name : Beijing Sevenstar Huachuang
Electronics Model No. :
L42500-4/ZM Capacity : 100pcs/run
per tube *Graphite Boat for
PECVD (for 156x156mm wafer)
100pcs/boat *Power Supply PEII5K
Advance Energy 1. S/N : 728041 2.
S/N : 728091 *ACT Stack to
Cassette Elec: 230V, 10A *AMI
Presco MTF-S1 Solar cell flipping
tool *AMI Presco MSP 9155A
printer *AMI USP206-2E Conveyer
for solar wafer AG exit to Despatch
furnace *Despatch CDF-7210
Furnace Serial No : 175365 *AMI
Presco UCL-TS solar wafer picking
and placing robot Serial No:
774206/07 *ACT solar wafer
picking tool, custom design * AMI
CP-885 printer * AMI UCL-TS Solar
wafer picking and place tool *
AMI MCD2400 Dryer (AL Dryer) *
AMI Presco ACL – TS post dryer solar
wafer picker s/n : 774201/07 *
Color Sorter Machine ASM B8-80329
Elec : 240V, 13A * dryer 1 Jing
Gang Dryer (custom made) 415V 3Ph,
20A * Control Unit 4 Control Box
for AMI Pick & Place Unit
Location: Port Klang , Malaysia Current status of the equipment:
warehoused and crated
Here is the capacity calculation:- 1200 X 4watt cells = 4,800 watts (these are LDK 4 watt Solar wafers) 4,800 watts X 24 Hr = 115,200 115,200 X 7 days = 806,400 Watts 806,400 X 52 Wks. = 41,932,800 watts 41,932,800 X .8 production = 33,546,240 Watts The tools have been de-installed and are presently stored in a climate controlled environment. The tools are not crated so you may do a visual inspection if desired. There are some video showing the line on youtube. Here are links to the videos: http://www.youtube.com/watch?v=jefuJsxBGDY http://www.youtube.com/watch?v=I7wetRMVri4 http://www.youtube.com/watch?v=IEeEiiciwWE http://www.youtube.com/watch?v=MDYs7vuNYiM http://www.youtube.com/watch?v=Ym5vzDv6EzU This system is used for the production of solar cells by the silk-screen printing process. This process allows the production of: -Conductors -Resistors -Dieelectrics -Glass protections -Cross-overs The loading of the system is carried out by a conveyer with vision system. Wafer cells arrive from a conveyer to a Baccini conveyer and here, by a vision system the cells are aligned and put on a walking beam, by adjusting the speed of the first conveyer you can obtain loading heaps of 4 or 6 cells. Printing head resolution is approx 0.5nm
20 MWp Model: Solar Description: Qty 2 Module
Manufacturing Lines Version: 450
cm x 230 cm Vintage: 01.06.2008 Quantity: 1 Sales Condition: as
is where is Lead Time:
find hereafter the information of 2
production lines of solar panels to
The lines are still
installed, and regularly maintained,
but not currently producing. We
recommend inspection of the equipment
to fully understand the conditions
of the machines. Dismantling and
re-installation service is
The first line was
manufactured and acquired in 2007
and started production on 2008 The second line was acquired on
2008. In 2009 and 2010 the lines
were in full production.
the end of 2011 the production
ceased due decrease of
demand. The lines start to
produce again from June 2012 to
September 2012, when they
ceased production definitively.
The acquired technology is SPIRE
SOLAR, a partnership between SPIRE
and NISSIHINDO, and the oven for
lamination is NISSIHINDO
Full production requires about
Each line has a capacity of 12 MGW,
so total capacity is 24 MGW. The
Cell sorter has a capacity of 20 MGW
and the simulator of 72 MGW (can
serve 6 lines)
can produce around 600 cells/hour
(depending obviously on the sizes of
In the laminators
the maximum size panels are 450 cm x
Please find attached
an excel with the inventory of the
machinery and pics of the
The lines are
fully automated , except the last
step (frame construction).
